Yamaha VF115 User Manual

Engine control system
41
EMU26806
Alert system
ECM00093
Do not continue to operate the engine if an
alert device has activated. Consult your
Yamaha dealer if the problem cannot be
located and corrected.
EMU43754
Overheat alert
This engine has an overheat-alert device. If
the engine temperature rises too high, the
alert device will activate.
 The engine speed will automatically de-
crease to 2000–3500 r/min.
 The overheat-alert indicator will light or
blink (if equipped).
 The buzzer will sound (if equipped on the
tiller handle, remote control box, or main
switch panel).
If the alert system has activated, stop the en-
gine and check the cooling water inlets:
 Check trim angle to be sure that the cooling
water inlet is submerged.
 Check the cooling water inlet for clogging.
EMU41182
Low oil pressure alert
The outboard motor is equipped with a low oil
pressure alert system. If the engine oil pres-
sure is low, the alert system will activate.
 The engine speed will automatically de-
crease to about 2000–3500 r/min.
 The low oil pressure-alert indicator will
come on or blink.
 The buzzer will sound.
ZMU01757
ZMU06297
ZMU07012
ZMU01828
U6FN36E0.book Page 41 Tuesday, November 30, 2021 8:08 AM

Yamaha VF115 Specifications

General

Engine Type	4-Stroke
Horsepower	115 hp
Cylinders	4
Displacement	1832 cc
Full Throttle RPM Range	5300-6300 rpm
Recommended Fuel	Regular Unleaded (Minimum Pump Octane 87)
Recommended Engine Oil	Yamalube 4M
Ignition System	TCI (Transistor Controlled Ignition)
Starting System	Electric
Gear Ratio	2.15:1
Steering	Remote
Trim Method	Power Trim & Tilt
Exhaust	Through Propeller
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	35A
Shaft Length	20", 25"
Dry Weight	377 lb
Warranty	3 years limited warranty
Bore x Stroke	81.0 mm x 88.9 mm (3.19 in x 3.50 in)
