Yamaha VF115 User Manual

Operation
59
TIP:
Depending on the type of boat, the outboard
motor trim angle may have little effect on the
trim of the boat when operating.
EMU27948
Tilting up and down
If the engine will be stopped for some time or
if the boat is moored in shallows, the out-
board motor should be tilted up to protect the
propeller and lower case from damage by
collision with obstructions, and also to re-
duce salt corrosion.
EWM01544
Make sure that all people are clear of the
outboard motor when tilting the outboard
motor up and down. Body parts can be
crushed between the outboard motor and
the clamp bracket when the outboard mo-
tor is trimmed or tilted.
ECM00993
 Before tilting the outboard motor, follow
the procedure under “Stopping engine”
in this chapter. Never tilt the outboard
motor while the engine is running. Se-
vere damage from overheating can re-
sult.
 To prevent the cooling water passages
from becoming frozen when the ambi-
ent temperature is 5°C (41°F) or below,
tilt the outboard motor up after it has
been stopped 30 seconds or more.
EMU44640
Procedure for tilting up (power trim
and tilt models)
(1) Place the remote control lever in neutral.
(2) Press the power trim and tilt switch “ ”
(up) until the outboard motor has tilted
up completely.
ZMU07040
ZMU07034
N
ZMU06926
N
U6FN36E0.book Page 59 Tuesday, November 30, 2021 8:08 AM

Yamaha VF115 Specifications

General

Engine Type	4-Stroke
Horsepower	115 hp
Cylinders	4
Displacement	1832 cc
Full Throttle RPM Range	5300-6300 rpm
Recommended Fuel	Regular Unleaded (Minimum Pump Octane 87)
Recommended Engine Oil	Yamalube 4M
Ignition System	TCI (Transistor Controlled Ignition)
Starting System	Electric
Gear Ratio	2.15:1
Steering	Remote
Trim Method	Power Trim & Tilt
Exhaust	Through Propeller
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	35A
Shaft Length	20", 25"
Dry Weight	377 lb
Warranty	3 years limited warranty
Bore x Stroke	81.0 mm x 88.9 mm (3.19 in x 3.50 in)
