Yamaha XVS1100 2001 - ELECTRICAL SPECIFICATIONS

–4–
MAINTENANCE SPECIFICATIONS
SPEC
ELECTRICAL
Item
Standard Limit
Ignition coil:
Model/manufacturer
Primary winding resistance
Secondary winding resistance
F6T541/MITSUBISHI
3.57  4.83 Ω at 20_C
10.7  14.5 kΩ at 20_C
SSS
SSS
SSS
Charging system:
Type
Model/manufacturer
Nominal output
Stator coil resistance/color
A.C. magneto
F4T654/MITSUBISHI
14 V 305 W at 5,000 r/min
0.36  0.44 Ω at 20_C/White – White
SSS
SSS
SSS
SSS
Electric starter system:
Type
Starter motor:
Model/manufacturer
Output
Armature coil resistance
Brush overall length
Brush spring pressure
Commutator diameter
Mica undercut
Starter relay:
Model/manufacturer
Amperage rating
Constant mesh type
SM-13/MITSUBA
0.6 kW
0.026  0.034 Ω at 20_C
10 mm
7.65  10.01 N (780  1021 g)
28 mm
0.7 mm
MS5F-421/JIDECO
180 A
SSS
SSS
SSS
SSS
5 mm
SSS
27 mm
SSS
SSS
SSS
