–19–
ADJUSTING THE HEADLIGHT BEAM
CHK
ADJ
a
b
a
b
EAS00184
ADJUSTING THE HEADLIGHT BEAM
1. Adjust:
headlight beam (vertically)
a. Turn the adjusting screw
1
in direction
a
or
b
.
Direction Headlight beam is raised.
Direction Headlight beam is
lowered.
2. Adjust:
headlight beam (horizontally)
a. Turn the adjusting knob
2
in direction
a
or
b
.
Direction Headlight beam moves to
the right.
Direction Headlight beam moves to
the left.
