DESCRIPTION
3-2
3
EAU10420
Right view
1 2 3,4,5,6 7
10 9
8
1112131415
1. Luggage strap holder (page 4-23)
2. Helmet cable holder (page 4-17)
3. Fuse box 1 (page 7-36)
4. Main fuse (page 7-36)
5. Fuel injection system fuse (page 7-36)
6. Battery (page 7-35)
7. Air filter element (page 7-20)
8. Coolant reservoir (page 7-18)
9. Radiator cap (page 7-18)
10.Engine oil filler cap (page 7-14)
11.Coolant drain bolt (page 7-19)
12.Engine oil dipstick (page 7-14)
13.Brake pedal (page 4-13)
14.Rear brake light switch (page 7-26)
15.Rear brake fluid reservoir (page 7-27)
U1JS11E0.book Page 2 Tuesday, August 2, 2011 3:03 PM
To Next Page
