30
SWING
A - FRAME
5/16” x 3” Lag Bolt
5/16” Lock Washer
5/16” Flat Washer
x4
SWING BEAM ASSEMBLY INSTALL
* USE CARE WHEN INSTALLING
SWING BEAM ASSEMBLY
* TWO PEOPLE AND A STEP LADDER ARE
RECOMMENDED FOR THIS STEP.
DO NOT OVER-TIGHTEN LAG BOLTS
