39
ROCK WALL INSTALL
CENTER
Flush at bottom of Deck Plank.
SWING BEAM SIDE
Center Rockwall / Ladder on deck joist
and mark hole positions.
BACK SIDE
ROCK WALL INSTALL
Pre-drill three 1/4" pilot holes at marked locations.
Re-drill holes from opposite side using 1/2" bit.
SEE PAGE 7
BACK SIDE
Rock Wall
