32
SWING
SWING BEAM
1-1/4” Hex Bolt
Lock Washer
Flat Washer
5/16" Flat Washer
5/16" Lock Washer
5/16" x 3" Lag Bolt
T-Nut x4
SWING TOP BRACKET
x4
x4
x1
2182
NOTE: Align 2182 bracket
with previously drilled
holes in swing beam.
DO NOT OVER-TIGHTEN LAG BOLTS
You may need to add
washers to make hex
bolt  ush with T-nut.
