6 SPECIFICATIONS
49
6.2 BRAKING UNIT FOR 575V CLASS APPLICATION
LIST
Example: 575-V Class Inverter Model CIMR-G5
Note: The above table lists the applicable braking unit and braking resistor unit models for the 575-V
class inverter model CIMR-G5. For other inverter models, refer to the catalog of the relevant
inverter.
Inverter Braking Unit Braking Resistor Unit Approx.
Braking
Torque
(10%ED)
%
Max Applicable
Motor Capacity
HP(kW)
Model
(CDBR-)
Unit Q’ty Resistor Spec.
5 (3.7) – – 560W 150Ω 180
7.5 (5.5) – – 560W 150Ω 125
10 (7.5) – – 750W 100Ω 140
15 (11) – – 1100W 75Ω 125
20 (15) – – 1500W 50Ω 140
25 (18.5) – – 2300W 40Ω 140
30 (22) 5037B 1 2800W 38Ω 125
40 (30) 5037B 1 3900W 33Ω 110
50 (37) 5037B 1 4900W 27Ω 110
60 (45) 5037B 2 5900W 22Ω 110
75 (55) 5037B 2 7200W 18Ω 110
100 (75) 5110B 1 9800W 13.6Ω 105
120 (90) 5110B 1 12000W 11Ω 110
150 (110) 5110B 1 15000W 9Ω 110
200 (160) 5300B 1 21000W 6.8Ω 100
