Configuring Advanced Features
169
CSeq: 2 INFO
Contact: <sip:827@10.1.4.148:5063>
Max-Forwards: 70
User-Agent: Yealink SIP-T28P 2.72.0.1
Record: on
Content-Length: 0
When the user presses the record key for the second time, the IP phone sends a SIP
INFO message to the server with the specific header “Record: off”, and then the
recording stops.
Example of a SIP INFO message:
Via: SIP/2.0/UDP 10.1.4.148:5063;branch=z9hG4bK1619489730
From: "827" <sip:827@192.168.1.199>;tag=1831694891
To:<sip:614@192.168.1.199>;tag=2228378244
Call-ID: 1051886688@10.1.4.148
CSeq: 3 INFO
Contact: <sip:827@10.1.4.148:5063>
Max-Forwards: 70
User-Agent: Yealink SIP-T28P 2.72.0.1
Record: off
Content-Length: 0
URL Record
When a user presses a URL record key for the first time during a call, the IP phone sends
an HTTP GET message to the server.
Example of an HTTP GET message:
Get /phonerecording.cgi?model=yealink HTTP/1.0\r\n
Request Method: GET
Request URI: /phonerecording.cgi?model=yealink
Request version: HTTP/1.0
Host: 10.1.2.224\r\n
User-agent: yealink SIP-T28P 2.72.0.1 00:16:65:11:30:68\r\n
If the recording is successfully started, the server will respond with a 200 OK message.
Example of a 200 OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
The recording session is successfully started.
</Text>
