YOKOGAWA WT310 User Manual

7-16
IM WT310-02EN
7.11 Ethernet Interface(/C7 Option)
Item Specifications
Ports 1
Connector type RJ-45
Electrical and mechanical
specifications
Complies with IEEE802.3
Transmission system Ethernet (100BASE-TX/10BASE-T)
Transfer rate 100 Mbps max.
Communication protocol TCP/IP
Supported services DHCP, remote control (VXI-11)
7.12 Safety Terminal Adapter
Item Specifications
Maximum allowable current 36 A
Dielectric strength 1000 V CATIII
Contact resistance 10
mΩorless
Contact section Nickel plating on brass or bronze
Insulator Polyamide
Maximum core wire diameter 1.8 mm
Maximum insulation diameter 3.9 mm
