IM WT310-02EN
1.6
System Configuration
Power
Supply
Load
VT
CT
V
oltage
(Apply one of them.)
Current
(Apply one of them.)
Current sensor
(op
tiona
l)
Remote control signal
(optional)
Int
ern
al
memo
ry
Nume
ric da
ta st
orage
Recorder
Nume
ric da
ta
Setup parameters
PC
Printer
Integration start
Integration stop
Hold/
single
USB interface/
GP-IB in
terface
*
/
RS-232 interface
*
/
Ethernet interface (optional)
D/A
output (option)
Measured values
are transmitted
as DC voltages.
WT310/WT310HC/WT330
*
The WT310/WT310HC/WT330 is standard-equipped with a GP-IB or RS-232 interface (whichever
you choose).
29
31
Table of Contents
