MAT ADJUSTMENT BOLTS
- USE ALLEN KEY TO ADJUST MAT AS INSTRUCTED BELOW.
SHOULD YOU REQUIRE ANY ASSISTANCE REGARDING THIS PRODUCT PLEASE CONTACT YORK DIRECTLY.
*
*
HOW TO ADJUST THE MAT ALIGNMENT AND TENSION
MAT MOVES TO RIGHT
If your mat tends to move to the right, then adjust the right screw by turning it a turn clockwise.
We recommend adjustments of a turn only at a time, then test each time.
If your mat continues to move to the right, simply adjust the left adjustment screw, by turning
a turn counterclockwise, test after each adjustment.
MAT MOVES TO LEFT
If your mat tends to move to the left, then the adjustment of the right screw is necessary by
turning it counterclockwise.
We recommend adjustments of turn only at a time, then test each time.
If the mat continues to move to the left, simply adjust the left adjustment screw, by turning
turn clockwise, then test each time.
The alignment and tension of the mat (walking surface) has been set prior to shipping.
Should improper tracking of the mat occur (walking surface moving too far to the right or the left
on the platform) or if you find that the mat slips when you get on, these problems can be corrected
as follows:
Locate the adjustment screws on the end of the main frame.
CAUTION: Adjust the mat when the treadmill is running at the lowest speed.
Keep others away from the treadmill.
Connect the safety key and set to the lowest speed.
TEST: Allow the mat to run for several minutes and watch to see if it runs in the center position
correctly. If the mat does not run in the center position, carry out the steps for:
”MAT MOVES TO LEFT” or “MAT MOVES TO RIGHT”.
Be sure that you adjust by “ a turn only each time” to avoid over correcting.
YORK T780 TM / 10
