22 Unitary Products Group
036-21311-003-A-0104
TYPICAL APPLICATIONS
TO POWER SUPPLY
SUPPLY AIR
DUCT
RETURN AIR
DUCT
TYPICAL SLAB ON GROUND INSTALLATION
FIELD SUPPLIED
DISCONNECT SWITCH
LOCATED TO REAR OF UNIT
CONTROL WIRING
TO INDOOR
THERMOSTAT
ROOF CURB
INSTALLATION
REAR DUCT
SLAB ON GROUND
INSTALLATION
ROOF CURB
INSTALLATION
BOTTOM DUCT
TYPICAL ROOF CURB INSTALLATION
SUPPLY AIR
DUCT
RETURN AIR
DUCT
CONTROL WIRING
TO INDOOR THERMOSTAT
TO POWER SUPPLY
FIELD SUPPLIED
DISCONNECT SWITCH
MOUNTED ON UNIT
