COOLING CAPACITIES - 2 TON (BHA024)
Temperature of Air on
Outdoor Coil
Air On Indoor Coil
600 CFM 700 CFM 800 CFM 900 CFM 1,000 CFM
WB°FWB°FWB°FWB°FWB°F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
25.3 23.1 20.8 20.8 26.4 24.1 21.7 21.6 27.4 25.0 22.5 22.5 28.1 25.6 23.1 23.0 28.7 26.2 23.6 23.5
Total Power
Input kW
2.21 2.18 2.14 2.12 2.26 2.23 2.18 2.16 2.30 2.27 2.22 2.20 2.33 2.30 2.25 2.22 2.35 2.32 2.27 2.25
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 15.1 18.8 20.8 20.8 16.7 20.9 21.7 21.6 18.4 22.9 22.5 22.5 19.9 24.5 23.1 23.0 21.4 26.2 23.6 23.5
83 13.4 17.1 20.1 20.6 14.7 18.8 21.3 21.5 16.1 20.6 22.5 22.5 17.3 22.0 23.1 23.0 18.5 23.5 23.6 23.5
80 11.6 15.4 18.4 18.9 12.7 16.8 20.0 20.6 13.8 18.2 21.7 22.3 14.6 19.4 22.6 22.9 15.5 20.5 23.6 23.5
77 9.9 13.7 16.7 17.2 10.7 14.8 18.0 18.6 11.4 15.9 19.4 20.0 12.0 16.7 20.0 20.3 12.5 17.5 20.6 20.5
74 8.2 12.0 14.9 15.4 8.7 12.8 16.0 16.5 9.1 13.6 17.1 17.6 9.3 14.0 17.3 17.6 9.5 14.5 17.6 17.6
71 - 10.3 13.2 13.7 - 10.8 14.0 14.5 - 11.2 14.7 15.3 - 11.4 14.7 14.9 - 11.5 14.6 14.6
68 - 8.6 11.5 12.0 - 8.7 12.0 12.5 - 8.9 12.4 13.0 - 8.7 12.0 12.3 - 8.6 11.7 11.6
95 °F
Net Cap
MBH
24.3 21.6 19.3 19.3 25.2 22.4 20.0 20.0 26.0 23.2 20.6 20.7 26.5 23.6 21.0 21.1 26.9 24.0 21.4 21.4
Total Power
Input kW
2.37 2.32 2.26 2.24 2.42 2.37 2.31 2.29 2.47 2.42 2.36 2.34 2.50 2.44 2.38 2.36 2.53 2.47 2.40 2.39
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 14.7 18.2 19.3 19.3 16.3 20.2 20.0 20.0 18.0 22.2 20.6 20.7 19.4 23.1 21.0 21.1 20.9 24.0 21.4 21.4
83 13.0 16.5 19.1 19.2 14.3 18.2 19.9 20.0 15.6 19.8 20.6 20.7 16.8 21.2 21.0 21.1 17.9 22.6 21.4 21.4
80 11.3 14.8 17.4 17.5 12.3 16.2 19.0 19.1 13.3 17.5 20.5 20.7 14.1 18.5 20.9 21.1 14.9 19.6 21.4 21.4
77 9.6 13.1 15.7 15.8 10.3 14.1 16.9 17.1 11.0 15.2 18.2 18.3 11.4 15.9 18.3 18.4 11.9 16.6 18.4 18.5
74 7.9 11.4 14.0 14.1 8.2 12.1 14.9 15.1 8.6 12.8 15.9 16.0 8.8 13.2 15.6 15.7 8.9 13.6 15.4 15.5
71 - 9.7 12.3 12.4 - 10.1 12.9 13.0 - 10.5 13.5 13.7 - 10.6 13.0 13.1 - 10.7 12.4 12.5
68 - 8.0 10.6 10.7 - 8.1 10.9 11.0 - 8.2 11.2 11.3 - 7.9 10.3 10.4 - 7.7 9.4 9.5
105 °F
Net Cap
MBH
22.2 19.5 17.9 17.9 23.0 20.2 18.5 18.4 23.7 20.8 19.1 19.0 24.1 21.2 19.4 19.4 24.6 21.6 19.8 19.8
Total Power
Input kW
2.53 2.45 2.41 2.39 2.58 2.51 2.46 2.44 2.64 2.56 2.51 2.49 2.67 2.59 2.54 2.52 2.70 2.62 2.57 2.54
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 13.9 17.3 17.9 17.9 15.5 18.8 18.5 18.4 17.1 20.3 19.1 19.0 18.6 21.0 19.4 19.4 20.1 21.6 19.8 19.8
83 12.2 15.6 17.6 17.6 13.5 17.3 18.4 18.3 14.8 19.0 19.1 19.0 16.0 19.9 19.4 19.4 17.1 20.9 19.8 19.8
80 10.4 13.9 15.9 15.9 11.5 15.3 17.5 17.5 12.5 16.6 19.0 19.0 13.3 17.7 19.4 19.4 14.1 18.8 19.8 19.8
77 8.7 12.2 14.2 14.2 9.4 13.2 15.4 15.4 10.1 14.3 16.7 16.7 10.6 15.1 16.8 16.7 11.1 15.8 16.8 16.8
74 7.0 10.5 12.5 12.5 7.4 11.2 13.4 13.4 7.8 12.0 14.4 14.3 8.0 12.4 14.1 14.1 8.2 12.9 13.9 13.8
71 - 8.8 10.8 10.8 - 9.2 11.4 11.4 - 9.6 12.0 12.0 - 9.8 11.4 11.4 - 9.9 10.9 10.8
68 - 7.1 9.1 9.1 - 7.2 9.4 9.4 - 7.3 9.7 9.7 - 7.1 8.8 8.8 - 6.9 7.9 7.8
115 °F
Net Cap
MBH
20.2 17.4 16.6 16.4 20.8 17.9 17.0 16.9 21.3 18.4 17.5 17.3 21.8 18.8 17.9 17.7 22.3 19.2 18.3 18.1
Total Power
Input kW
2.69 2.59 2.56 2.53 2.75 2.64 2.61 2.58 2.80 2.70 2.67 2.64 2.84 2.73 2.70 2.67 2.87 2.77 2.73 2.70
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 13.0 16.4 16.6 16.4 14.7 17.4 17.0 16.9 16.3 18.4 17.5 17.3 17.8 18.8 17.9 17.7 19.3 19.2 18.3 18.1
83 11.3 14.7 16.2 16.0 12.7 16.4 16.8 16.7 14.0 18.1 17.5 17.3 15.2 18.7 17.9 17.7 16.3 19.2 18.3 18.1
80 9.6 13.0 14.4 14.3 10.6 14.4 16.0 15.8 11.7 15.8 17.5 17.3 12.5 16.9 17.9 17.7 13.4 18.0 18.3 18.1
77 7.9 11.3 12.7 12.6 8.6 12.4 14.0 13.8 9.3 13.4 15.2 15.0 9.9 14.2 15.2 15.1 10.4 15.1 15.3 15.1
74 6.2 9.6 11.0 10.9 6.6 10.3 11.9 11.8 7.0 11.1 12.8 12.7 7.2 11.6 12.6 12.4 7.4 12.1 12.3 12.1
71 - 7.9 9.3 9.2 - 8.3 9.9 9.8 - 8.8 10.5 10.3 - 8.9 9.9 9.7 - 9.1 9.3 9.2
68 - 6.2 7.6 7.5 - 6.3 7.9 7.7 - 6.4 8.2 8.0 - 6.3 7.3 7.1 - 6.1 6.4 6.2
125 °F
Net Cap
MBH
18.1 15.4 15.2 14.9 18.5 15.7 15.6 15.3 19.0 16.1 16.0 15.7 19.4 16.5 16.3 16.0 19.9 16.9 16.7 16.4
Total Power
Input kW
2.8 2.7 2.7 2.7 2.9 2.8 2.8 2.7 3.0 2.8 2.8 2.8 3.0 2.9 2.9 2.8 3.0 2.9 2.9 2.9
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 12.2 15.5 15.2 14.9 13.9 16.0 15.6 15.3 15.5 16.6 16.0 15.7 17.0 16.7 16.3 16.0 18.5 16.9 16.7 16.4
83 10.5 13.8 14.7 14.4 11.8 15.5 15.3 15.0 13.2 17.2 16.0 15.7 14.4 17.4 16.3 16.0 15.6 17.6 16.7 16.4
80 8.8 12.1 13.0 12.7 9.8 13.5 14.5 14.2 10.8 14.9 16.0 15.7 11.7 16.1 16.4 16.0 12.6 17.3 16.7 16.4
77 7.1 10.4 11.3 11.0 7.8 11.5 12.5 12.2 8.5 12.6 13.7 13.3 9.1 13.4 13.7 13.4 9.6 14.3 13.8 13.4
74 5.4 8.7 9.5 9.3 5.8 9.4 10.4 10.1 6.2 10.2 11.3 11.0 6.4 10.8 11.1 10.7 6.6 11.3 10.8 10.5
71 - 7.0 7.8 7.6 - 7.4 8.4 8.1 - 7.9 9.0 8.7 - 8.1 8.4 8.1 - 8.3 7.8 7.5
68 - 5.2 6.1 5.8 - 5.4 6.4 6.1 - 5.6 6.7 6.3 - 5.5 5.7 5.4 - 5.3 4.8 4.5
1
= These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY

York Champion Series Specifications

General

Series	Champion Series
Refrigerant	R-410A
Warranty	10-Year Limited Parts Warranty
Type	Heat Pump
SEER Rating	Up to 19
HSPF Rating	Up to 10
Compressor Type	Scroll
