York DC SERIES User Manual

5120410-XIM-B-0216
12 Johnson Controls Unitary Products
Detail A
Detail B
Table 8: DC090-150 Unit Clearances Imperial
Direction Distance (in.) Direction Distance (in.)
Top
1
1. Units must be installed outdoors. Over hanging structure or shrubs should not obscure condenser air discharge outlet.
72 Right 12
Front 36 Left 36
Rear 36 Bottom
2
2. Units may be installed on combustible floors made from wood or class A, B or C roof covering materials.
0
Table 9: DC090-150 Unit Clearances Metric
Direction Distance (mm) Direction Distance (mm)
Top
1
1. Units must be installed outdoors. Over hanging structure or shrubs should not obscure condenser air discharge outlet.
1829 Right 305
Front 914 Left 914
Rear 914 Bottom
2
2. Units may be installed on combustible floors made from wood or class A, B or C roof covering materials.
0
42”/1067mm CABINET
Ø 3.126
Ø 2.000
3.184
4.727
7.705
14.594
Gas Pipe Inlet
Gas Exhaust Vent
50 3/4”/1289mm CABINET
Ø 3.126
Ø 2.000
3.184
4.737
7.715
17.541
Gas Pipe Inlet
Gas Exhaust Vent
(81)
(51)
(587)
(120)
(371)
(196)
NOTE: (XXX) Indicates Millimeters
5-3/8
3/4” FPT
(137)
(19.05)
NOTE: (XXX) Indicates Millimeters
