York TM8V C Series User Manual

5402847-UIM-A-0917
Johnson Controls Unitary Products 29
Table 14: Air Flow Data
HIGH / LOW SPEED COOLING AND HEAT PUMP CFM
060A12 080B12 080C16
Jumper Settings
HIGH COOL LOW COOL HIGH COOL LOW COOL HIGH COOL LOW COOL
COOL Tap ADJ Tap*
1277 825 1241 834 1644 1054
A B
1067 709 1064 720 1447 927
B B
1162 762 1147 782 1489 955
A A
972 667 960 678 1321 857
B A
1046 699 1043 709 1349 871
A C
857 615 855 605 1236 815
C B
888 615 866 615 1166 787
B C
678 499 678 501 1012 703
D B
783 573 793 563 1096 759
C A
625 478 626 459 927 660
D A
720 531 720 521 998 703
C C
583 478 574 459 843 604
D C
100C16 100C20 120C20
Jumper Settings
HIGH COOL LOW COOL HIGH COOL LOW COOL HIGH COOL LOW COOL
COOL Tap ADJ Tap*
1674 1069 2244 1380 2244 1437
A B
1463 943 1744 1149 1783 1188
B B
1519 971 2032 1284 2032 1322
A A
1336 858 1572 1053 1610 1072
B A
1378 1013 1821 1149 1840 1188
A C
1238 816 1495 1015 1533 1034
C B
1168 788 1399 957 1437 957
B C
1027 690 1284 880 1341 880
D B
1111 760 1360 938 1399 938
C A
929 633 1188 823 1207 823
D A
1013 676 1245 842 1284 842
C C
844 591 1092 765 1130 746
D C
HIGH / LOW HEAT CFM
060B12 080B12 080C16
Jumper Settings
HIGH HEAT LOW HEAT HIGH HEAT LOW HEAT HIGH HEAT LOW HEAT
HEAT Tap ADJ Tap*
1111 963 1480 1284 1480 1289 A Any
988 825 1317 1100 1317 1100
B Any
889 722 1185 963 1185 960
C Any
808 642 1077 856 1077 855
D Any
100C16 100C20 120C20
Jumper Settings
HIGH HEAT LOW HEAT HIGH HEAT LOW HEAT HIGH HEAT LOW HEAT
HEAT Tap ADJ Tap*
1851 1604 1851 1604 2220 1925 A Any
1646 1375 1646 1375 1975 1651
B Any
1481 1204 1481 1204 1778 1444
C Any
1347 1070 1347 1070 1616 1284
D Any
All CFMs are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0” to 0.6” w.c.
static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than 1.0” w.c. external static
pressure is not recommended.
NOTE: At some settings, LOW COOL and/or LOW HEAT airflow may be lower that what is required to operate an airflow switch on certain models of electronic air clean-
ers. Consult the instructions for the electronic air cleaner for further details.
* The ADJ “D” tap should not be used.
