York V* Series User Manual

Unitary Products Group 13
246681-YTG-B-0607
TABLE 8: SPECIFICATIONS AND ELECTRICAL DATA - 2800 THROUGH 3600 CFM ERV’S
Model Numbers
VR036 - Rooftop Stationary
VS036 - S/S Stand Alone
VO036 - O/U Stand Alone
Line Voltage - 60hz 208/230v-3ph 460v-3ph 575v-3ph 208/230v-3ph 460v-3ph 575v-3ph
Fresh Air
Blower
Motor - hp / type 3 / Belt 2 / Belt
Wheel Size (dia x width) - in 12 x 9 12 x 9
Motor Speed - rpm 1725 1725
Motor Speed(s) Adjustable Sheave Adjustable Sheave
Bearing Type Ball Ball
Full Load Amps 9.4 4.3 3.2 6.6 3.3 2.4
Service Factor 1.15 1.15
Exhaust Air
Blower
Motor - hp Stationary 3 / Belt 2 / Belt
Wheel Size (dia x width) - in 12 x 9 12 x 9
Motor Speed - rpm 1725 1725
Motor Speed(s) Adjustable Sheave Adjustable Sheave
Bearing Type Ball Ball
Full Load Amps-Stationary 9.4 4.3 3.2 6.6 3.3 2.4
Service Factor 1.15 1.15
Wheel
Electrical
Data
Motor - hp (1 phase) 0.50 0.50
Potential Volts 200-208 / 230 200-208 / 230
Motor Speed - rpm 1725 1725
Full Load Amps 2.7 2.7
Total
Electrical
MCA - Stationary 22.4 10.9 8.4 16.1 18.6 6.6
OCPD - Stationary 30 15 9 20 12 9
Wheel
Data
Wheel Depth x Diameter - in 3 x 41.825 3 x 41.825
Construction / Media Type Segmented Pies / Polymeric Segmented Pies / Polymeric
Enthalpy
Wheel ARI
Rating Data
Nominal Airflow CFM 3100 @ .9Δ 3100 @ .9Δ
EATR - -1.00 H
2
O 4.90% 4.90%
EATR - 0.00 H
2
O 1.30% 1.30%
EATR - +1.00 H
2
O 0.30% 0.30%
OACF - -1.00 H
2
O 0.99% 0.99%
OACF - 0.00 H
2
O 1.07% 1.07%
OACF - +1.00 H
2
O 1.12% 1.12%
Thermal Ratings @ 0” Pressure Diff. Sensible Latent Total Sensible Latent Total
Total
Effective-
ness
100% Airflow Heating 68% 60% 65% 68% 60% 65%
75% Airflow Heating 74% 67% 71% 74% 67% 71%
100% Airflow Cooling 68% 60% 63% 68% 60% 63%
75% Airflow Cooling 74% 67% 70% 74% 67% 70%
Net
Effective-
ness
100% Airflow Heating 68% 60% 65% 68% 60% 65%
75% Airflow Heating 74% 67% 71% 74% 67% 71%
100% Airflow Cooling 68% 60% 63% 68% 60% 63%
75% Airflow Cooling 74% 67% 70% 74% 67% 70%
Curb A/C Unit Curb Height - in 24 24
Weights
Shipping Weight - lbs. 571 571
Net Weight - lbs. 475 475
