YORK UERV MODEL NOMENCLATURE
* CFM is ERV wheel rating. This may vary depending on unit cabinet pressure drop. ** These CFM ranges are dependant upon blower motor selection. *** Only options available for VR074 & VR122.
Digit
Example Model #
Model Description Options
1 V Product Category V = Ventilator 2 R Wheel Type
R= Rooftop Stationary H= Horizontal O= Stand Alone Over and Under, Stationary S= Stand Alone Side by Side
P= Rooftop Pivoting (036-060 & 078-150 only) U= Upflow
3, 4 & 5 028 CFM*
006= 300 to 550 011= 600 to 1000 020= 1100 to 1700 028= 2200 to 2800** 1500 to 2200**
036= 2800 to 3600 046= 3400 to 4600 062= 5500 to 6200** 4800 to 5600** 074= 6000 to 8000
122= 8000 to 13000
6, 7 & 8 A12
York Rooftop Cabinet
A05= D*NA/NH/NP 018-060 B05= D*EB/EH/EM 018-060 & B*HA/HH/HP 018-060 A06= DM/DF/DH 036-072 & BQ 036-060 A12= DM/DF/DH/DJ 078-150 & BP078-150
A15= DM/DH 180 & BP 180 A25= DM/DH 240-300, DJ180-300, DR180-300 & BQ 240 A40= B12=
Stand Alone N00= None York Furnace / Air Handler Cabinet
Z02=P*DH/P*XD-V 10-037 Z03=P*UR/P*XU/PXU-V 8-037 X03=N*AH/N*VS B--G2FD 16-024S,030S,036S Z04=P*HU/P*DU/P*DU-V/P*HU-L/P*DU-L 16-064,080 Z04=P*UR/P*XU/PXU-V 10-055 Y04=N*AH/N*VS B--G2FD 16-036S,042S,048S Z05=P*HU/P*DU/P*DU-V/P*HU-L/P*DU-L 20-064,080,092 Z05=P*UR/P*XU/PXU-V 16-075 Z05=P*UR/P*XU/PXU-V 20-095 Y05=P*UR/P*XU/PXU-V 20112,130 X05=P*DH/P*XD-V 20-075 V05=N*AH/N*VS B--G2FD 14/20-048S,060S,061H
Z03=P*HU/P*DU/P*DU-V/P*HU/P*DU-L 12-032, 048, 060 Y03=P*DH/P*XD-V 12-055,075 W03=G*C 12-050,075 Z04=P*HU/P*DU/P*DU-V/P*HU-L/P*DU-L 12-080 Z04=P*UR/P*XU/PXU-V 12-075 X04=G*C 16-075,100 Z05=P*HU/P*DU/P*DU-V/P*HU-L/P*DU-L 16-092 Z05=P*UR/P*XU/PXU-V 14-095 Y05=P*HU/P*DU/P*DU-V/P*HU-L/P*DU-L 20-104 X05=P*DH/P*XD-V 16-075 W05=P*DH/P*XD-V 20-112 U05=G*C 20-100,125,150
9 H Blower Speed
H = High Speed** M = Mediu Speed**
V = Variable Speed (VR074 only) L = Constant Volume (VR122)
10 4 Voltage
1= 110v-1ph 2= 208/230v-3ph 4= 460v-3ph
5= 575v-3ph 8= 460v-1ph 9= 208/320v-1ph
11 W Duct Type A= no selection on Rooftop Units W= Wall Sleeve (Upflow Only) D = Ducted System 12 & 13 L2 Additional Options
AA= No Option L1= Low Ambient Kit (LAK) * L2= LAK & Motorized Outside Air (MOA) * L3= LAK, MOA & Stop-Start-Job (SSJ) (
not used on P models) *
L4= LAK, MOA, SSJ & Pressure Sensor (
PS) (not used on P)
L5= LAK & SSJ (
not used on P models) *
L6= LAK, SSJ & PS (
not used on P models)
L7= LAK & PS
L8= LAK, MOA and PS M1= Motorized Outside Air (MOA) * M2= MOA, and Stop Start-Jog (SSJ) (
not used on P models) *
M3= MOA, SSJ and Pressure Sensor (PS) (
not used on P models)
M4= MOA and PS S1= Stop-Start-Job (SSJ) (
not used on P models) *
S2= SSJ and Pressure Sensor (PS) (
not used on P models)
P1= Pressure Sensor (PS)
14 1 Product Generation 1= 1st Generation
