138
JOHNSON CONTROLS
FORM 201.21-NM1 (1223)
FIG. 14 - CHILLER CONTROL BOARD, RELAY BOARDS, AND MICROGATEWAY
LD10580
COMPONENT LOCATIONS (CON'T)
TECHNICAL DATA
CHILLER
CONTROL
BOARD
MICROGATEWAY
(OPTIONAL)
RELAY BOARD #1
RELAY BOARD #2
RS-232/485 JUMPER
CLOCK JUMPER (CLK)
JP2
JP4, JP5, & JP6
mA
• • •
V
â–¼
â–² â–²
â–¼
JUMPER POSITION
