236
JOHNSON CONTROLS
FORM 201.21-NM1 (1223)
OPERATING HOURS / START COUNTER KEY
LD10605
OPERATING HOURS/
START COUNTER
KEY
Operating Hours/Start Counter Key Operation
Compressor operating hours and compressor starts are
displayed with a single key press. The maximum value
for both hours and starts is 99,999, at which point they
will roll over to 0. A single display is available under
this key and is displayed below. On 2 and 3 compressor
units, the data and compressor designators for compres-
sors not present are blanked out.
HOURS 1=XXXXX, 2=XXXXX, 3=XXXXX, 4=XXXXX
START 1=XXXXX, 2=XXXXX, 3=XXXXX, 4=XXXXX
MICRO PANEL
