23
JOHNSON CONTROLS
FORM 201.21-NM1 (1223)
2
COMPLETE PIN NUMBER DESCRIPTION (CON'T)
Feature Description Option Description
BAS BAS Interface (PIN 21)
X No BAS Reset/O󰀨set required
T BAS/EMS Temp Reset/O󰀨set
C BAS/EMS Current Reset/O󰀨set
B BAS/EMS Both Temp and Current Reset/O󰀨set
M ISN Microgateway
Q Special BAS Reset/O󰀨set required
LCD LCD (PIN 22)
X English LCD & Keypad Display (std)
S Spanish LCD & Keypad Display
F French LCD & Keypad Display
G German LCD & Keypad Display
I Italian LCD & Keypad Display
P Portuguese LCD & Keypad Display
Q Special LCD & Keypad Display
RDOUT Silent Night (PIN 23)
X No option required
N Silent Night sound limiting control option
Q Special quote
SAFETY Safety Code (PIN 24)
L
(Std. 60 Hz) N. American Safety Code
(cUL/cETL)
N (Std 50 HZ) No listing
Q Special Safety Code
SENSOR PIN 25
X No option required
Q Special quote
PUMP Pump Control (PIN 26)
X No Pump Control required
Q Special Pump Control required
REMOTE Remote Ctrl Panel (PIN 27)
X No Remote Control Panel required
O Optiview Remote Control Panel required
Q Special Remote Control Panel required
SEQ Sequence Kit (PIN 28)
X No Sequence Kit required
S
Sequence Control & Automatic Lead Transfer =
{seq}
Q Special Sequence Kit required
TEMP Water Temp (PIN 29, 30)
NUM Leaving Water Temp. = {temp} degrees
TS Thermal Storage
QQ Special LWT requirements
CHICAGO Chicago Code Kit (PIN 31)
X No Chicago Code Kit required
C Chicago Code Kit required
S Service Isolation Valve
B Both Isolation Valve and Chicago Code
Q Special Chicago Code Kit required
VALVES Valves (PIN 32)
X Standard Valves required
Q Special Optional Valves required
HGBP PIN 33
X No option required
Q Special quote
GAUGE PIN 34
X No option required
Q Special quote
OVERLOAD PIN 35
X No option required
Q Special quote
PIN36 PIN 36
X No option required
Q Special quote
HTR Crankcase Heater (PIN 37)
H Compressor Crankcase Heaters
Q Special quote
DWP DWP (PIN 38)
X 150psig DWP
3 300psig DWP
Q Special DWP
