50
JOHNSON CONTROLS
FORM 201.21-NM1 (1223)
Model Number
/Nameplate
System 1 System 2
Control
KVA
8
Unit Short Circuit
Withstand (KA)
Compressor
RLA
6
Cond. Fans Compressor
RLA
6
Cond. Fans
YCAV
Input
Volts
Input
Freq
Qty FLA
(EA)
Qty FLA
(EA)
Terminal
Block
(STD)
Circuit
Breaker
(OPT)
0157
200 60 254 4 6.5 254 4 6.5 1.8 30KA 100KA
230 60 220 4 5.6 220 4 5.6 1.8 30KA 100KA
380 60 139 4 3.5 139 4 3.5 1.8 30KA 65KA
460 60 110 4 2.8 110 4 2.8 1.8 30KA 65KA
575 60 88 4 2.2 88 4 2.2 1.8 30KA 42KA
0177
200 60 257 5 6.5 281 4 6.5 1.8 30KA 100KA
230 60 223 5 5.6 244 4 5.6 1.8 30KA 100KA
380 60 140 5 3.5 154 4 3.5 1.8 30KA 65KA
460 60 111 5 2.8 122 4 2.8 1.8 30KA 65KA
575 60 89 5 2.2 97 4 2.2 1.8 30KA 42KA
0187
200 60 356 5 6.5 242 5 6.5 1.8 30KA 100KA
230 60 308 5 5.6 210 5 5.6 1.8 30KA 100KA
380 60 194 5 3.5 132 5 3.5 1.8 30KA 65KA
460 60 154 5 2.8 105 5 2.8 1.8 30KA 65KA
575 60 123 5 2.2 84 5 2.2 1.8 30KA 42KA
0197
200 60 326 5 6.5 326 5 6.5 1.8 30KA 100KA
230 60 283 5 5.6 283 5 5.6 1.8 30KA 100KA
380 60 178 5 3.5 178 5 3.5 1.8 30KA 65KA
460 60 141 5 2.8 141 5 2.8 1.8 30KA 65KA
575 60 113 5 2.2 113 5 2.2 1.8 30KA 42KA
0207
200 60 327 6 6.5 353 5 6.5 1.8 30KA 100KA
230 60 283 6 5.6 306 5 5.6 1.8 30KA 100KA
380 60 178 6 3.5 193 5 3.5 1.8 30KA 65KA
460 60 141 6 2.8 152 5 2.8 1.8 30KA 65KA
575 60 113 6 2.2 122 5 2.2 1.8 30KA 42KA
0227
200 60 347 6 6.5 347 6 6.5 1.8 30KA 100KA
230 60 301 6 5.6 301 6 5.6 1.8 30KA 100KA
380 60 190 6 3.5 190 6 3.5 1.8 30KA 65KA
460 60 150 6 2.8 150 6 2.8 1.8 30KA 65KA
575 60 120 6 2.2 120 6 2.2 1.8 30KA 42KA
0247
200 60 449 6 6.5 344 6 6.5 1.8 30KA 100KA
230 60 389 6 5.6 298 6 5.6 1.8 30KA 100KA
380 60 245 6 3.5 188 6 3.5 1.8 30KA 65KA
460 60 193 6 2.8 148 6 2.8 1.8 30KA 65KA
575 60 155 6 2.2 119 6 2.2 1.8 30KA 42KA
HIGH EFFICIENCY 2-Compressor Units (See FIG. 7)
(One Field Provided Power Supply Circuit to the Chiller.
Field Connection to Factory provided Terminal Block (Standard)
or Circuit Breaker (optional).
TECHNICAL DATA
