DIMENSIONS - YCAV0157S/P Standard E󰀩ciency English (Con't)
LD10521A
230 3/8"
110 1/4"90"
88 1/8"
96"
40"
14 1/16"
87 3/8"
1,933 2,098 1,435
1,301 1,984 1,666
5/8" MOUNTING
HOLES (TYP.)
APPROX. OPERATING WEIGHT
DISTRIBUTION (LB)
X
G
C
Y
G
C
X
Z
D D
VIEW D-D
CONTROL PANEL
8"
WATER OUTLET
8"
WATER INLET
1"
1"
48 1/2"64"108 1/2"
A
A
(3) RIGGING HOLES
EACH SIDE (4.5 X 2)
SYS. 2 SYS. 1
11 1/2"
85 7/16"100 7/8"
ORIGIN
6"
3 3/4"
10"
1,091
1,055
68"
60"
