Table 1. Cooling capacities YCSA 120, 150 T and TP
Table 2. Cooling capacities YCSA 120 - 150 T and TP (35% ethylene glycol)
Table 3. Correcting factors for other glycol concentrations
If it is necessary to make a selection with different glycol percentages, correct the capacity and obsorbed power values in Table 2 (35% ethylene glycol),
multiplying them by the coefficients indicated in Table 3.
Model
Water
outlet
temp.
°C
Outdoor ambient temperature °C DB (80% HR)
25 30 32 35 40 43 45
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
YCSA
120
T and
TP
5
128.9 36.4 119.7 39.6 116.1 40.9 110.7 41.7 101.6 46.1 96.0 47.9 92.3 50.9
6
132.1 37.0 123.2 40.0 119.6 41.3 114.2 42.1 105.3 46.9 99.8 48.6 96.3 51.3
7
135.4 37.6 126.6 40.4 123.0 41.9 119.0 43.0 109.0 47.6 103.6 49.2 100.2 51.7
8
138.6 38.3 130.1 40.8 126.5 42.6 121.4 43.9 112.7 48.4 107.6 49.9 104.1 52.1
10
145.2 39.3 136.9 41.7 133.5 43.9 128.5 44.7 120.2 49.2 115.2 50.6 111.9 52.9
12
152.0 40.1 143.3 43.3 139.9 44.7 134.9 46.7 126.6 50.0 121.5 51.9
15
161.6 43.0 153.0 45.9 149.6 47.0 144.6 48.7 136.1 51.6
YCSA
150
T and
TP
5
168.9 42.4 156.9 46.1 152.3 47.6 145.1 48.5 133.2 53.6 125.9 55.8 121.1 59.2
6
173.2 43.1 161.5 46.6 156.8 48.1 149.8 49.0 138.1 54.5 130.9 56.5 126.2 59.6
7
177.5 43.8 166.0 47.0 161.3 48.8 156.0 50.0 142.9 55.4 135.9 57.3 131.4 60.1
8
181.7 44.5 170.5 47.5 165.8 49.5 159.1 51.0 147.7 56.3 141.0 58.0 136.5 60.6
10
190.3 45.7 179.4 48.5 175.0 51.0 168.5 52.0 157.6 57.2 151.0 58.8 146.6 61.5
12
199.2 46.6 187.8 50.4 183.5 52.0 176.9 54.3 166.0 58.1 159.3 60.4
15
211.8 50.1 200.6 53.4 196.1 54.7 189.5 56.7 178.5 60.0
Model
Water
outlet
temp.
°C
Outdoor ambient temperature °C DB (80% HR)
25 30 32 35 40 43 45
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
Cap.
kW
Unit
kW
YCSA
120
T and
TP
-5
78.0 28.8 73.0 31.1 70.9 32.2 67.7 32.9 62.5 36.7 59.3 37.8 56.6 40.7
-4
81.8 29.5 76.5 31.9 74.3 32.9 70.9 33.6 65.5 37.6 62.2 38.7 59.0 41.7
-2
89.7 30.9 84.0 33.3 81.5 34.5 77.8 35.2 71.9 39.3 68.2 40.5 64.4 43.5
0
98.1 32.3 91.9 34.8 89.1 36.0 85.0 36.8 78.7 41.1 74.5 42.3 69.8 45.2
2
107.1 33.7 100.3 36.4 97.4 37.6 92.9 38.5 85.9 43.0 81.4 44.2 77.6 47.0
4
116.2 35.2 108.7 37.9 105.6 39.2 100.8 40.1 93.2 44.8 88.3 46.1 84.3 49.6
YCSA
150
T and
TP
-5
102.3 33.5 95.7 36.2 92.9 37.4 88.7 38.2 82.0 42.7 77.8 43.9 74.2 47.3
-4
107.2 34.3 100.3 37.0 97.4 38.3 93.0 39.1 85.9 43.7 81.5 44.9 77.3 48.5
-2
117.6 35.9 110.1 38.8 106.9 40.1 102.0 41.0 94.3 45.7 89.4 47.0 84.4 50.6
0
128.6 37.5 120.4 40.5 116.9 41.9 111.5 42.8 103.1 47.8 97.7 49.2 91.5 52.6
2
140.4 39.2 131.5 42.3 127.6 43.8 121.8 44.7 112.6 50.0 106.7 51.4 101.8 54.6
4
152.3 40.9 142.5 44.1 138.4 45.6 132.1 46.6 122.1 52.1 115.8 53.6 110.5 57.6
% in weight
Ethylene glycol Propylene glycol
Capacity Absorbed power Capacity Absorbed power
10 1.061 1.025 1.097 1.033
20 1.036 1.015 1.067 1.023
30 1.015 1.005 1.026 1.008
35 1.000 1.000 1.000 1.000
40 0.985 0.995 0.974 0.992
50 0.954 0.985 0.923 0.977
