Table 6. Available pressure for the hydraulic
circuit, YCSA/YCSA-H 120, 150 with kit (With
filter fitted)
Table 7. Pressure drop in the hydraulic circuit,
YCSA/YCSA-H 120, 150 without kit (Without filter
fitted)
Table 8. Pressure drop filter
2 1/2" filter
Data with water at 10°C.
In the case of the use of glycol, apply the correcting factors shown in Tables 2 and 3.
Model Flow l/h Kpa
YCSA/YCSA-H 120 TP
15 000 310
16 000 295
17 000 279
18 000 261
19 000 241
20 000 217
21 000 187
22 000 157
23 000 123
24 000 90
25 000 55
YCSA/YCSA-H 150 TP
18 000 249
19 000 243
20 000 237
21 000 230
22 000 223
23 000 215
24 000 207
25 000 199
26 000 192
27 000 183
28 000 175
29 000 165
30 000 155
31 000 145
32 000 132
33 000 120
34 000 109
35 000 95
36 000 84
37 000 70
38 000 57
Model Flow l/h
Kpa
YCSA/YCSA-H 120 T
15 000 18
16 000 20
17 000 23
18 000 25.5
19 000 28
20 000 31
21 000 34
22 000 37
23 000 40
24 000 43
25 000 46
26 000 49
27 000 52.5
28 000 56.5
29 000 60
30 000 63
31 000 67
32 000 70.5
33 000 74.5
34 000 78
YCSA/YCSA-H 150 T
18 000 12.5
19 000 14
20 000 15.5
21 000 17.5
22 000 19.5
23 000 21.5
24 000 23.5
25 000 25.5
26 000 27.5
27 000 30
28 000 32.5
29 000 35
30 000 37.5
31 000 40
32 000 43
33 000 46
34 000 49
35 000 52
36 000 55
37 000 58
38 000 61
39 000 64
40 000 67
41 000 70
42 000 73
Flow l/h 15 000 16 000 17 000 18 000 19 000 20 000 21 000 22 000 23 000 24 000 25 000 26 000 27 000 28 000
Kpa
2 2.20 2.40 2.7 3.0 3.3 3.6 4.0 4.4 4.8 5.2 5.6 6.0 6.5
Flow l/h 29 000 30 000 31 000 32 000 33 000 34 000 35 000 36 000 37 000 38 000 39 000 40 000 41 000 42 000
Kpa
7 7.5 8 8.5 9.0 9.7 10.5 11.3 12.1 13.0 14 15 16 17
