16
Above 150mm
Above 500mm
Above 500mm
Above 200mm
Above 300mm
Above 150mm
Above 300mm
Above 150mm
Above 150mm
Above 500mm
Above 300mm
Fig. 18
Above 150mm
Above 300mm
Back and side
Height of bariers is below that of outdoor unit.
Above 300mm
Above 300mm
Above 200mm
Above 300mm Above 300mm
Fig. 19
3. If there is obstruction at front side and obstruction
is lower than unit,the backside,top side and flank
sides shall be kept open.
5. When there is obstruction in all four directions
Even if the top side is open,the unit can not be
installed there.
2. When the front side (air outlet) is open and
obstruction is lower than unit, if we can keep the
space as shown in the gure, this position is still
feasible even if there is obstruction in other three
sides. (The top side is open.)
4. When there is obstruction at both front side
and backside, plaese don't choose the following
location.
6. While installing the outdoor unit,enough
maintenance space shall be prepared,as shown in
the following gure.
1. Single unit mounting
2. Multi-unit installation (unit: mm)
Installation of the Outdoor Unit
1. When there is obstruction above the unit ,if we
can keep the space as shown in the gure,this
position is still feasible.
To Next Page
