JOHNSON CONTROLS2
FORM 150.68-EG1 (0212)
NOMINAL DATA
NOMENCLATURE
YLPA Model 0115SE 0145SE 0170SE
Capacity (TONS) 118 146 167
Capacity (kW) 414 515 587
Capacity (MBH) 1390 1731 2037
Capacity (kW) 412 510 612
(1) At 54/44°F chilled water temperatures and 95°F ambient.
(2) At 104/113°F hot water temperatures and 44°F ambient.
Cooling Mode
(1)
Heating Mode
(2)
YLPA
0115S
E
40XB
A
1 2 3 4
5 6 7 8 9 10 11 12 13 14 15
BASE PRODUCT TYPE NOMINAL CAPACITY UNIT DESIGNATION REFRIGERANT VOLTAGE / STARTER DESIGN / DEVELOPMENT LEVEL
Y
: York
####
kW
S
: Standard Unit
E
: R-410A
40
X
: 380 / 3 / 60
B
: Design Series
L
: Scroll
0115 0145 0170
X
: Direct on Line
A
: Development Level
P
: Heat Pump
A
: All Regions
Introduction
CONTENTS
Introduction .................................................................................................................................................................................................................. 2
Product Description .................................................................................................................................................................................................... 3
Microcomputer Control Center .................................................................................................................................................................................. 4
Accessories and Options ........................................................................................................................................................................................... 5
Refrigerant Flow Block Diagrams .............................................................................................................................................................................. 6
Component Location ................................................................................................................................................................................................... 7
Application Data .......................................................................................................................................................................................................... 8
Connection Diagram ................................................................................................................................................................................................. 14
Water Pressure Drop ................................................................................................................................................................................................. 15
Ratings ....................................................................................................................................................................................................................... 16
Technical Data ........................................................................................................................................................................................................... 19
Dimensions ................................................................................................................................................................................................................ 21
