1183875-YIM-A-1014
Johnson Controls Unitary Products 19
Figure 23: Field Wiring Disconnect - Cooling Unit With Gas Heat Without VFD Option
L1
T1
L2
T2
T3
L3
THREE
PHASE
POWER
SUPPLY
FACTORY OR FIELD
SUPPLIED DISCONNECT
GROUND
LUG
CONTACTOR 1M
