D. SPECIFICATIONS
Model
Spec.
PC
LCD Display Active matrix TFT LCD Panel
Max. Resolution
1024×768 XGA/ 15”，1280×1024 SXGA/ 17”&19”
1400×1050 SXGA/ 20.1” , 1680×1050 WSXGA/ 22”
1366×768 WXGA/ 26” & 32” & 37” & 42”
Contrast Ratio
□300：1 □350：1 □400：1 □500：1
Brightness
□200cd/㎡ □250cd/㎡ □400cd/㎡ □500cd/㎡
Response Time 10/30ms
Display Color 16777M
Viewing Angle L/R
□120° □140° □160° □170° □178°
U/D
□110° □120° □160° □170° □178°
PC Interface Video RGB analog 0.7V pp
Sync. TTL positive or negative
Display Mode CGA/EGA/VGA/SVGA/XGA/SXGA/WXGA/WSXGA
PC connect
□15 pin D-sub □ DVI
Front Control
Power on/off with LED, Menu select, Up/Down
Adjustment, Auto tuning, Light sensor
OSD Adjustment
Contrast, Brightness, Auto tuning, Phase-position,
V-position, Input selection
Power Input
AC Input：100-240V, 50-60Hz
Power Adapter
AC Input：100-240V, 50-60Hz
DC Output：12V/4.0A
Operating Conditions
Temperature：0℃～50 , Humidity: 20℃ ﹪～80﹪
Storage Conditions
Temperature：-20℃～60℃, Humidity: 20﹪～80﹪
OPTION ITEMS
Model
Spec.
Speaker AV DVI
- 10 -
Input Signal Analog Composite Y/C TMDS
Audio Input
Connector
Phone Jack RCA No
Video Input
Connector
No S&RCA DVI-D
