13.3.4 Config menu “SET MODEL” functions list
To enter the CONFIG MENU it is necessary to push in the same time the right side
top and left side top buttons. Then roll until the SET MODEL item appears on the
hand set display. Push the ENTER button (see the Figure 13.3.4-1 below).
1) Opening Zapi Menu
EPSWSM 1Q NA4.98
48V 70A 00000
2) Press Top Left & Right Buttons to enter
CONFIG MENU
% ' %
' ' '
3) The Display will show: SET MODEL
CONFIG MENU
SET MODEL
4) Press ENTER to go into the SET MODEL
MENU
' % '
' ' '
5) The display will show:
SYSTEM CONFIG
LEVEL= 0
6) Press ROLL UP or ROLL DOWN button until
the desired parameter is reached
% ' '
% ' '
7) The desired parameter appears
MODEL TYPE.
0
8) Press SET UP or SET DOWN button to modify
the adjustment
' ' %
' ' %
MODEL TYPE.
1
9) Press OUT
' ' '
' % '
10) Press ENTER to confirm
' % '
' ' '
11) Repeat the same from 5 to 10 points for the
other adjustments
Figure 13.3.4-1
