18 PERIODIC MAINTENANCE TO BE
REPEATED AT TIMES INDICATED
Check the screws to couple the steering gear box to the truck frame are
tightened.They should be checked every 3 months.
Check the screws to couple the steering gear box to the motor are tightened.
They should be checked every 3 months.
Check the screws to couple the steering motor flanges are tightened.
They should be checked every 3 months.
Check the wires in the ampseal connector are tightened. Ensure the female
connector is tightly coupled with its counterpart.
Wires should be checked every 3 months.
U Checks should be carried out by qualified personnel and any replacement
parts used should be original. Beware of NON ORIGINAL PARTS.
The installation of this electronic controller should be made according to
the diagrams included in this Manual. Any variations or special
requirements should be made after consulting a Zapi Agent. The supplier is
not responsible for any problem that arises from wiring methods that differ
from information included in this Manual.
During periodic checks, if a technician finds any situation that could cause
damage or compromise safety, the matter should be bought to the attention
of a Zapi Agent immediately. The Agent will then take the decision
regarding operational safety of the machine.
Remember that Battery Powered Machines feel no pain.
NEVER USE A VEHICLE WITH A FAULTY ELECTRONIC CONTROLLER.
18.1 Testing the faulty detection circuitry
U The material handling directive EN1175 requires periodic testing of the
controller’s fault detection circuitry to be checked in one of the following
modes (choose the one you prefer):
Switch on the key and try to disconnect the stepper motor. An alarm,
stopping the traction should immediately occur
Try to disconnect the +B to the steering assembly. After switching on the
key an alarm stopping the traction should immediately occur as soon as
the steering (or handle) wheel rotates
