Zebra DS2208 Product Reference Guide

Symbologies 11 - 5
I 2 of 5 Reduced Quiet Zone 1210 F8h 04h BAh Disable 11-52
Discrete 2 of 5 (DTF)
Discrete 2 of 5 5 05h Disable 11-52
Set Lengths for D 2 of 5 20, 21 14h 15h 1 to 55 11-53
Codabar (NW - 7)
Codabar 7 07h Enable 11-55
Set Lengths for Codabar 24, 25 18h, 19h 4 to 55 11-55
CLSI Editing 54 36h Disable 11-57
NOTIS Editing 55 37h Disable 11-57
Codabar Upper or Lower Case Start/
Stop Characters Detection
855 F2h 57h Upper Case 11-58
MSI
MSI 11 0Bh Disable 11-58
Set Lengths for MSI 30, 31 1Eh, 1Fh 4 to 55 11-59
MSI Check Digits 50 32h One 11-61
Transmit MSI Check Digit 46 2Eh Disable 11-61
MSI Check Digit Algorithm 51 33h Mod 10/Mod 10 11-62
MSI Reduced Quiet Zone 1392 F8h 05h 70h Disable 11-62
Chinese 2 of 5
Chinese 2 of 5 408 F0h 98h Disable 11-63
Matrix 2 of 5
Matrix 2 of 5 618 F1h 6Ah Disable 11-63
Matrix 2 of 5 Lengths 619
620
F1h 6Bh
F1h 6Ch
4 to 55 11-64
Matrix 2 of 5 Check Digit 622 F1h 6Eh Disable 11-66
Transmit Matrix 2 of 5 Check Digit 623 F1h 6Fh Disable 11-66
Korean 3 of 5
Korean 3 of 5 581 F1h 45h Disable 11-67
Inverse 1D 586 F1h 4Ah Regular 11-68
Table 11-1 Symbology Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS2208 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Connectivity technology	Wired
Certification	EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07 IEC 62471 EN 55022 (Class B); EN 55032 (Class B) EN 55024 EN 61000-3-2 EN 61000-3-3 47 CFR Part 15, Subpart B, Class B ICES-003 Issue 6, Class B
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS
Cables included	Micro-USB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery life	100 h
Battery capacity	2400 mAh
Power consumption	250 mA
Power source type	DC
AC adapter output voltage	5 V
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	66 mm
Height	165 mm
Weight	161.6 g
