Zephyr Siena Pro ZSP-E36BS User Manual

11
SURFACE MAINTENANCE:
Clean the hood surface periodically with hot soapy water and clean cotton cloth. Do not use corrosive or
abrasive detergent, or steel wool/scouring pads which will scratch and damage surface.
For heavier soil use liquid degreaser.
After cleaning it is recommended that you use non-abrasive stainless steel polish/cleaners, to polish and
EXႇRXWWKHVWDLQOHVVOXVWHUDQGJUDLQ$OZD\VVFUXEOLJKWO\ZLWKFOHDQFRWWRQFORWKDQGZLWKWKHJUDLQ
Do not use any product containing chlorine bleach. Do not use “orange” cleaners.
%DႉH)LOWHUV
7KHEDႉH¿OWHUVLQVWDOOHGE\WKHIDFWRU\DUHLQWHQGHGWR¿OWHURXWUHVLGXHDQGJUHDVHIURPFRRNLQJ7KH\
QHHGQRWEHUHSODFHGRQDUHJXODUEDVLVEXWDUHUHTXLUHGWREHNHSWFOHDQ
5HPRYHDQGFOHDQE\KDQGRULQGLVKZDVKHURQORZKHDW6SUD\GHJUHDVLQJGHWHUJHQWDQGOHDYHWRVRDNLI
heavily soiled.
'U\¿OWHUVDQGUHLQVWDOOEHIRUHXVLQJKRRG
5HPRYLQJ%DႉH)LOWHUV
1. Push in on spring loaded handle
3XOOGRZQRQ¿OWHUKDQGHWRUHPRYH¿OWHU
6KRXOG¿OWHUVZHDURXWGXHWRDJHDQGSURORQJHGXVH
replace with following part number:
Maintenance – Cleaning, Filter Care & Part List
LIST OF PARTS & ACCESSORIES
DESCRIPTION PART#
Replacement Parts
%DႉH)LOWHUHDFK 
Optional Accessories
Duct Cover Extension Kit Z1C-00SP
8QLYHUVDO0DNH8S$LU'DPSHU 08$$
To order parts, visit us online at http://store.zephyronline.com or call us at 1.888.880.8368

Zephyr Siena Pro ZSP-E36BS Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	ducted, external
Temperature Sensor	no
Number of Fan Speeds	5
Duct Diameter	10 inches
Duct Length	14 1/2 inches
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts
Current	9 amperes

Weight and Dimensions

Depth	21 15/16 inches
Height	27 1/2 inches
Width	35 7/8 inches
Net Weight	62 pounds
