Zephyr Siena Pro ZSP-E36BS User Manual

12
www.zephyronline.com
Maintenance – Lights
LED LIGHT STRIPS
,QWKHXQOLNHO\HYHQWWKDW\RXU/('VWULSIDLOVSOHDVHFRQWDFW=HSK\UWRRUGHUUHSODFHPHQWSDUWV
6HHOLVWRISDUWVDQGDFFHVVRULHVSDJHIRUSDUW¶VDQGFRQWDFWLQIRUPDWLRQ
To replace LED light strip
5HPRYHDOXPLQXPPHVK¿OWHUV
2. Remove light panel by two screws.
'LVFRQQHFW/('OLJKWVWULSTXLFNFRQQHFWRU
4. Push in the two side clips on the ends of the LED strip.
5. Push LED light strip through the light panel opening.
Push the clip

Zephyr Siena Pro ZSP-E36BS Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	ducted, external
Temperature Sensor	no
Number of Fan Speeds	5
Duct Diameter	10 inches
Duct Length	14 1/2 inches
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts
Current	9 amperes

Weight and Dimensions

Depth	21 15/16 inches
Height	27 1/2 inches
Width	35 7/8 inches
Net Weight	62 pounds
