Zephyr Siena Pro ZSP-E36BS User Manual

Installation – Mounting Height & Clearance
6
www.zephyronline.com
DUCTING
A minimum of 10” round duct is recommended to
PDLQWDLQPD[LPXPDLUÀRZHႈFLHQF\
Always use rigid type metal ducts only. Flexible
GXFWVFRXOGUHVWULFWDLUÀRZE\XSWR
8VHFDOFXODWLRQZRUNVKHHWRQSDJHWRFRPSXWH
WRWDOGXFWZRUN
ALWAYS, when possible, reduce the number of
transitions and turns. If a long duct run is required,
increase duct size from 10” to 12”.
If turns or transitions are required: Install as far
away from opening and as far apart, between 2,
as possible.
Minimum mount height between range top to hood
bottom should be no less than 24”.
Maximum mount height should be no higher than
34”.
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
UHVXOWLQKHDWGDPDJHDQG¿UHKD]DUGZKLOHKRRGV
mounted too high will be hard to reach and will
ORRVHLWVSHUIRUPDQFHDQGHႈFLHQF\
If available, also refer to range manufacturer’s
height clearance requirements and recommended
KRRGPRXQWLQJKHLJKWDERYHUDQJH$OZD\VFKHFN
\RXUORFDOFRGHVIRUDQ\GLႇHUHQFHV
'XFWFRYHUH[WHQVLRQNLWDYDLODEOHIRUFHLOLQJ
heights up to 12 feet. Turn to page 11 for part
number and ordering information.
DAMAGE-SHIPMENT / INSTALLATION:
• Please fully inspect unit for damage before
installation.
• If the unit is damaged in shipment, return the
unit to the store in which it was bought for
repair or replacement.
• If the unit is damaged by the customer, repair
or replacement is the responsibility of the
customer.
 ,IWKHXQLWLVGDPDJHGE\WKHLQVWDOOHULIRWKHU
WKDQWKHFXVWRPHUUHSDLURIUHSODFHPHQWPXVW
be made by arrangement between customer
and installer.
24” min.
34” max.
min. A
max. B
min. C
max. D
Standard Extension
Hood Heights Duct Cover Duct Cover
minimum (A) 27-1/2” 45“
maximum (B) 42” 78”
Ceiling Heights
minimum (C) 87-1/2” (7’ 3-1/2”) 105“ (8‘ 9”)
maximum (D) 112” (9’ 4“ ) 148” (12’ 4”)
36”

Zephyr Siena Pro ZSP-E36BS Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	ducted, external
Temperature Sensor	no
Number of Fan Speeds	5
Duct Diameter	10 inches
Duct Length	14 1/2 inches
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts
Current	9 amperes

Weight and Dimensions

Depth	21 15/16 inches
Height	27 1/2 inches
Width	35 7/8 inches
Net Weight	62 pounds
