Tagging & Untagging JesterML Operating Manual
73-406-00 Issue 3.0 41 of 85
NOTES
16-bit parameters
The Most-Significant-Byte (MSB) and Least-Significant-Byte (LSB) of 16-bit
parameters are tagged or untagged together. It is not possible to tag or untag the
MSB separately from the LSB.
16-bit parameters are displayed on the desk as two sets of values (eg 127-255) to
indicate the level of both channels.
Virtual Channels
Fixtures without a brightness channel (e.g. some LED products) can have a Virtual
Intensity channel on the desk which will govern the output levels of linked channels.
Grand Master & Blackout will also then govern these channels. This information is
set up in the fixture library and with the Fixture Type Editor tool. For information on
fixture profiles, see the Fixture Tools User Guide.
