185
ESSENTIAL TECHNICAL PARAMETERS
FORWARD TRAVEL SPEED OF THE TRACTOR - 40 KM/H
Speed of the tractor in km/h at nominal
speed of the engine (2,200 rpm) and given
sizes of rear wheel tyres
Speed of dependent rear
output shaft 540/1000 at
nominal speed of the engine
(2,200 rpm)
Speed of dependent rear
output shaft 540/540E at
nominal speed of the engine
(2,200 rpm)
Gear
Multiplier
stage
16,9 - 34 18,4 -34 18,4 - 30 13,6 - 36 540 ot 1000 ot 540 ot 540E ot
4 Hi H 36.0 37.2 34.8 34.6 712.5 1344.4 1061.9 1344.4
L 27.7 28.6 26.8 26.6 712.5 1344.4 1061.9 1344.4
3 Hi H 24.8 25.6 24.0 23.8 490.5 925.5 731.0 925.5
L 19.1 19.7 18.5 18.3 490.5 925.5 731.0 925.5
2 Hi H 15.5 16.0 15.0 14.9 306.7 578.7 457.1 578.7
L 11.9 12.3 11.5 11.4 306.7 578.7 457.1 578.7
1 Hi H 10.7 11.06 10.34 10.27 211.7 399.4 315.4 399.4
L 8.23 8.51 7.95 7.90 211.7 399.4 315.4 399.4
4 Lo H 9.11 9.42 8.80 8.74 180.5 340.7 269.1 340.7
L 7.02 7.26 6.78 6.74 180.5 340.7 269.1 340.7
3 Lo H 6.27 6.48 6.06 6.02 124.3 234.5 185.2 234.5
L 4.83 4.99 4.67 4.64 124.3 234.5 185.2 234.5
2 Lo H 3.92 4.05 3.79 3.76 77.7 146.6 115.8 146.6
L 3.02 3.12 2.92 2.90 77.7 146.6 115.8 146.6
1 Lo H 2.71 2.80 2.62 2.60 52.3 98.7 77.9 98.7
L 2.08 2.15 2.01 2.00 52.3 98.7 77.9 98.7
Hi – road gears
Lo – reduced gears
H – higher stage of the multiplier
L – lower stage of the multiplier
