AP3/30_AP3/50_AP3/80_AP3/100_Instructions. V1.01 Page 2 August / 2012
Specication
Product: Zip Aquapoint III
Type: Direct unvented
Capacity: 30 litre, 50 litre, 80 litre, 100 litre
Loading: 3.0kW/230V~
Fuse Rating: 15A
Thermostat: Adjustable 25ºC to 75ºC
Thermal cut-out: Manually re-settable set to 84+0/-5ºC
Water vessel: Glass enamelled steel tested to 1.3 MPa (13 bar)
Maximum working pressure 0.6 MPa (6 bar)
Insulation: High performance foam insulation
Controls: Pressure reducing valve and line strainer set to 0.35 MPa (3.5 bar)
Expansion relief and single check valve set to 0.6 MPa (6 bar)
Pressure and temperature relief valve set to 0.7 MPa (7 bar) and 90ºC
External expansion vessel pre-charged to 0.35 MPa (3.5 bar)
Expansion vessel capacity: 5 litre AP3/30, AP3/50
8 litre AP3/80, AP3/100
Approvals Zip Aquapoint III complies with LVD and EMC directives and is CE
endorsed.
Zip Aquapoint III has been examined, tested and found, when correctly
tted,tocomplywiththerequirementsoftheUnitedKingdomWater
Regulations/Byelaws (Scotland). The product, therefore, is listed under the
WRAS (Water Regulations Advisory Scheme) Water Fitting and Materials
Directory.
Performance
Model Size
Heat up time
(15°C to 65°C)
Re-heat time
(70% vol.)
AP3/30 30 Litre 37 mins. 23 mins.
AP3/50 50 Litre 58 mins. 38 mins.
AP3/80 80 Litre 88 mins. 58 mins.
AP3/100 100 Litre 110 mins. 72 mins.
