ZXR10 2600 Product Description
ZTE Confidential Proprietary © 2009 ZTE Corporation. All rights reserved. 5
3 Functionality
3.1 Security functions
• Supporting multiple address table, static and dynamic table items, address filtering,
port address restriction, automatic learning, CPU learning, and learning prohibition.
• Supporting 802.1x authentication, port MAC binding, port separation, user
hierarchical management and password protection.
• Supporting broadcast, multicast and unicast packet suppression.
• Supporting standard 802.1Q and port-based VLAN. Supporting GVRP, STP, MSTP,
RSTP and supporting VLAN stacking.
3.2 Supporting L2 protocols
• Supporting IGMP Snooping, DHCP.
• Supporting STP, RSTP and MSTP. Supporting hybrid networking of the above
mentioned protocols.
• Supporting IEEE802.3ad LACP, supporting LACP (802.3AD).cross-device is
implemented in case of stacking.
• IEEE802.1x user authentication.
• Supporting standard Ethernet protocol suites of IEEE802.3, IEEE802.3u,
IEEE802.3z, IEEE802.3ab, IEEE802.3ad, and IEEE802.3x etc.
• Supporting MAC address binding and port separation.
3.3 Service functions
• MDI/MDIX self-twisted cable: getting rid of the complexity of cable type
distinguishing in practice and reducing workload of network installation and
maintenance.
• Port mirroring: supporting ingression mirroring and egression mirroring. Cross-
device can be implemented for mirroring source and destination in case of Flow
control: half-duplex supports counter pressure. Full duplex supports 802.3x.

Zte ZXR10 2600 Specifications

General

Model	ZXR10 2600
Category	Network Router
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
