ABB AC 800M Installation Manual

Thick Cable Section 2 Transmission Media and Components
22 9ARD000015-600
Thick Cable
Figure 6 shows the physical configuration of Thick cable.
Table 4 provides the various specifications of Thick cable and their corresponding
table numbers.
Figure 6. Thick Cable Physical Configuration
Table 4. Specifications for Thick Cable and their Corresponding Table Numbers
Characteristics Table Number
Data Pair Specification
Physical
Table 5
Electrical
Table 6
DC Power Specification
Physical
Table 7
Electrical
Table 8
General Specification
Physical
Table 9
