Technical data
126
Materials
Drive enclosure • PC/ABS 2.5 mm, colour NCS 1502-Y (RAL 9002 / PMS 420 C)
• hot-dip zinc coated steel sheet 1.5 to 2 mm, thickness of coating 100 micrometres
• cast aluminium AlSi (R2 and R3)
• extruded aluminium AlSi (R4 to R6)
Package Depends on the frame size and selected options: cardboard, heavy duty cardboard or
plywood, EPS cushions (expanded polystyrene), wooden pallet
Plastic covering of the package: PE-LD, bands PP or steel.
Disposal The main parts of the drive can be recycled to preserve natural resources and energy.
Product parts and materials should be dismantled and separated.
Generally all metals, such as steel, aluminum, copper and its alloys, and precious metals
can be recycled as material. Plastics, rubber, cardboard and other packaging material can
be used in energy recovery. Printed circuit boards and DC capacitors (C1-1 to C1-x) need
selective treatment according to IEC 62635 guidelines. To aid recycling, plastic parts are
marked with an appropriate identification code.
Contact your local ABB distributor for further information on environmental aspects and
recycling instructions for professional recyclers. End of life treatment must follow
international and local regulations.
Applicable standards
• EN 50178:1997 Electronic equipment for use in power installations
• EN 60204-1:2006 +A1:2009 Safety of machinery. Electrical equipment of machines. Part 1: General requirements.
Provisions for compliance: The final assembler of the machine is responsible for installing
- an emergency-stop device
- a supply disconnecting device.
• EN 60529:1991
+ corrigendum May 1993
+ A1:2000
Degrees of protection provided by enclosures (IP code)
• IEC 60664-1:2007 Insulation coordination for equipment within low-voltage systems. Part 1: Principles,
requirements and tests.
• EN 61800-3:2004 Adjustable speed electrical power drive systems. Part 3: EMC requirements and specific
test methods
• UL 508C (2002) UL Standard for Safety, Power Conversion Equipment, second edition
• NEMA 250 (2003) Enclosures for Electrical Equipment (1000 Volts Maximum)
• CSA C22.2 No. 14-05
(2005)
Industrial control equipment
