Electrical installation
69
8. Tighten the clamping nuts of the cable glands.
After connecting the control cables, fasten the front covers.
Warning sticker
There are warning stickers in different languages inside the packing box of the drive.
Attach a warning sticker in the language of your choice onto the plastic skeleton
above the power cable terminals.
Wire size Compression lug Crimping tool
MCM/AWG Manufacturer Type Manufacturer Type No. of crimps
6 Burndy YAV6C-L2 Burndy MY29-3 1
Ilsco CCL-6-38 Ilsco ILC-10 2
4 Burndy YA4C-L4BOX Burndy MY29-3 1
Ilsco CCL-4-38 Ilsco MT-25 1
2 Burndy YA2C-L4BOX Burndy MY29-3 2
Ilsco CRC-2 Ilsco IDT-12 1
Ilsco CCL-2-38 Ilsco MT-25 1
1 Burndy YA1C-L4BOX Burndy MY29-3 2
Ilsco CRA-1-38 Ilsco IDT-12 1
Ilsco CCL-1-38 Ilsco MT-25 1
Thomas & Betts 54148 Thomas & Betts TBM-8 3
1/0 Burndy YA25-L4BOX Burndy MY29-3 2
Ilsco CRB-0 Ilsco IDT-12 1
Ilsco CCL-1/0-38 Ilsco MT-25 1
Thomas & Betts 54109 Thomas & Betts TBM-8 3
2/0 Burndy YAL26T38 Burndy MY29-3 2
Ilsco CRA-2/0 Ilsco IDT-12 1
Ilsco CCL-2/0-38 Ilsco MT-25 1
Thomas & Betts 54110 Thomas & Betts TBM-8 3
