7
3.2 Use of Controls – Fig. 3.2(a) to (f)
Frame 1
Frame 2
Frame 3
Frame 4
Page 1
Frame 1
Frame 2
Frame 3
Page 2
Return from
any frame
Lift/Lower pen on alternate operations
Acknowledge any alarm
Auto-tune
Pen lift/lower
Profile ramp soak
Local /Remote
or
Return operator to top of
Operating Page
.
Parameter 1
Parameter 2
Op. Page
Parameter 1
Parameter 2
Page X
Parameter 1
Parameter 2
Page X
Auto/Manual switch – used for selecting
Automatic or Manual mode on alternate
operations. When manual mode is selected the
displays revert automatically to the process
variable values and control output or valve
position (if position-proportioning or boundless
motorized valve control is selected at Control
Type in the Set Up Control Page).
Frame 1
Frame 2
Frame 3
Page X
Frame 4
Advance to
next Frame
Adjust
Parameter Value
Parameter X
Y
Z
Select
3 DISPLAYS & CONTROLS
Fig. 3.3(a) Advancing to Next Page
Fig. 3.3(b) Moving Between Parameters
✶
Note. Continued pressure on the and
switches causes the rate of change of the
displayed value to increase. To make small
adjustments operate the switches momentarily.
Fig. 3.3(c) Adjusting a Parameter Value
✶
Note. Continued pressure on the and
switches causes the rate of change of the
displayed value to increase. To make small
adjustments operate the switches momentarily
Fig. 3.3(d) Selecting a Parameter Choice
✶
Note. If 'Auto Pen Drop' is selected in the Set
Up Chart Page, BASIC CONFIGURATION LEVEL,
the pens automatically return to their operating
positions after a five minute delay.
Fig. 3.3(e) Lifting/Lowering the Pens
Information. The switch is programmed in
the Set Up Function Keys Page, ADVANCED
CONFIGURATION LEVEL.
✶
Note. The switch only returns the
instrument display to the start of the operating page
when at the top of any page.
Fig. 3.3(f) Selecting Programmable Functions
Fig. 3.3(g) Auto/Manual Switch Functions
To Next Page
