ABB DHH805-A User Manual

Handheld communicator Model DHH805-A | OI/DHH805-EN Rev. D 25
7 HART
®
Communication
7.11.2 Device Setup - TTX200 Temperature Transmitter
IDENTIFY
Tag
Poll addr
Manufacturer
Model
Dev id
Software rev
Hardware rev
Write protect
Descriptor
Message
Date
CONFIGURE
SENSOR
Select sensor probe type
Sensor probe type
Sensor wire number
Sensor resistance two wire
Sensor Uppper Limit
Sensor Lower Limit
Sensor Min Span
Select sensor probe type
Sensor probe type
Sensor CJC type
Sensor CJC temperature unit
Sensor CJC temperature
Sensor Uppper Limit
Sensor Lower Limit
Sensor Min Span
PARAMETERIZE
SENSOR
Sensor probe type
Sensor wire number
Sensor resistance two wire
Sensor Uppper Limit
Sensor Lower Limit
Sensor Min Span
Sensor probe type
Sensor CJC type
Sensor CJC temperature
Sensor Uppper Limit
Sensor Lower Limit
Sensor Min Span
CURRENT OUTPUT
PV Unit
Range (4mA)
To (20mA)
Damping
Reaction on errors
Underrange value
Overrange value
SIMULATE
Loop test
CALIBRATE
SENSOR TRIM
One point trim
Reset trim
CURRENT OUTPUT TRIM
D/A trim
EXTRA
Reset to factory
OBSERVE
OBSERVE
PV % rnge
Analog Value
Sensor (PV)
Electronics Temperature (SV)
Electrical Input (TV)
DIAGNOSE
DEVICE STATE
Device state
APPLICATION
Application
Application
Application
Application
Application
Application
SENSOR
Sensor
Sensor
Sensor
Sensor
Sensor
Sensor
ELECTRONICS
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Electronics
Important. DD structure changes according to instrument design.
