Link/Activity LED
DescriptionLED status
No link, no activityOFF
Link establishedGREEN
ActivityGREEN, flickering
Ethernet interface
The Ethernet interface operates at 100 Mbit, full duplex, as required by PROFINET
specification.
Cables and connectors
Cables used to connect the PROFINET network must comply with Cat 5 balanced
LAN requirements or better according to ISO/IEC 11801. For details see PROFINET
Cabling and Interconnection Technology available from www.profinet.com.
Application manual - PROFINET Anybus Device 21
3HAC050968-001 Revision: C
© Copyright 2008-2016 ABB. All rights reserved.
2 Hardware overview
2.1 Main computer DSQC1000
Continued
