18 Mechanical installation
Installing the module
WARNING! Obey the safety instructions. See chapter
Safety instructions on page 7. If you ignore the safety
instructions, injury or death can occur.
…onto the drive control unit
1. Pull out the lock.
2. Put the module carefully into its position on the drive until the
retaining clips lock it into position.
3. Push in the lock.
4. Tighten the screw to 0.8 N·m.
Note: The screw tightens the connections and grounds the
module. It is necessary for fulfilling the EMC requirements and
for proper operation of the module.
WARNING! Do not tighten the screw tighter than 0.8 N·m.
Too big torque value breaks the thread.
See the applicable drive manual for further instructions on how to
install the module to the drive.
