Master protocol
IEC 61107 (metering)
Alpha Meter protocol
RCOM
Table 5.2.1-2 Slave protocols
Slave protocol
IEC 60870-5-101, Single or redundant
IEC 60870-5-104, Single or redundant
DNP 3.0 LAN/WAN
DNP 3.0 Serial
RP 570/RP 571
F4F Westinghouse, No gateway support
Modbus RTU (CPI)
HSI features5.2.2.
The following table lists the SYS 600C HSI features.
Table 5.2.2-1 User interface options
ValueDescriptionUser interface option
0...5This is the number of work-
places that are in use simultan-
eously. The number of work-
places needed is defined in the
following way: - A workplace
means a computer (PC,
Laptop, PDA, ThinClient),
which can have one or several
physical screens from where
ONE person at a time can
operate. - Several Application
Windows can be used in one
workplace.
Nr of Pro workplaces
Yes/NoSelect this option, if you want
to use Process Displays in the
workplaces. Process Displays
means displays with zooming,
panning, and decluttering func-
tions typically used to present
the primary process, for
example, single-line diagram.
Process displays
Yes/NoSelect this option, if you want
to use dynamic network color-
ing in the Process Displays.
Network coloring
27
SYS 600C 1.92
MicroSCADA Pro
1MRS756804
Product Guide
