EMI/EMS and environmental standard compliance6.2.
The following tables list the EMI/EMS and environmental standard compliance.
Table 6.2-1 IEC 61850-3 standard compliance
Severity levelDescriptionType test
Level 4 -±8KV Contact/±15KV
Air
Electrostatic DischargeIEC 61000-4-2-2001
Level 3-18V/m, 6 directionsRadiated RF SucceptibilityIEC 61000-4-3-2006
Level 4- ±4KV 5KHzFast Transient (Burst Immunity)IEC 61000-4-4-2004
Level 4 ±4KV line-to-
earth/±2KV line-to-line
Surge ImmunityIEC 61000-4-5-2005
Level 3-10VrmsConducted RF ImmunityIEC 61000-4-6-2006
Level 5- 100A/m 5min /
1000A/m 1s
Magnetic Field ImmunityIEC 61000-4-8-2001
Level 4- 30A/mDamped Magnetic ImmunityIEC 61000-4-10-1993
Level 3-2.5KV common/Differ-
ential 1.25KV for Substation
Damped Oscillatory BurstIEC 61000-4-12-1995
Level 3-15Hz~150KHzConducted RF ImmunityIEC 61000-4-16-2002
30% 120ms/ 70% 10ms 100%
3ms (cycle 3)
Voltage Dips & InterruptsIEC 61000-4-29-2000
Class AConducted and Radiated
Emissions
CISPR22-2008
Class AConducted and Radiated
Emissions
FCC 15
Class AConducted and Radiated
Emissions
EN55022A
500VDC, 1min,
999Mohm>100Mohm
Insulation resistance measure-
ment
IEC 60255-5
25Amps, 1min,
0.021ohm<0.1ohm
Protective bonding resistanceIEC 60255-27
Table 6.2-2 IEEE Std 1613-2003 standard compliance
Severity levelDescriptionType test
Level 4- ±4KV 5KHz All portsEFTIEEE C37.90.1
Level 4 -±8KV Contact/±15KV
Air
ESDIEEE C37.90.3
Level 3-2.5KV common/Differ-
ential 1.25KV for Substation
Oscillatory WaveIEEE C37.90.1
2000VrmsDielectric StrengthIEEE C37.90
5000VImpulse VoltageIEEE C37.90
-20%~+15%DC Voltage RangesIEC 60870-2-1-1995
34
1MRS756804
MicroSCADA Pro
SYS 600C 1.92
Product Guide
