ABB NALF Series Mounting And Operation Manual

21.0 Reference list of fuses
These fuse links has been tested, according to IEC
62271-105 with air switch-disconnector Type NALF
Discon-
nector
Type of
fuse links
Rated
voltage
Un [kV]
Rated
current
[A]
Length
[mm]
Diameter
[mm]
NALF 12
CEF 3.6/7.2 6 192/292 65
CEF 3.6/7.2 10 192/292 65
CEF 3.6/7.2 16 192/292 65
CEF 3.6/7.2 25 192/292 65
CEF 3.6/7.2 40 192/292 65
CEF 3.6/7.2 50 192/292 65
CEF 3.6/7.2 63 192/292 65
CEF 3.6/7.2 80 192/292 87
CEF 3.6/7.2 100 192/292 87
CEF 3.6/7.2 125 192 87
CEF 12 6 292/442 53/65
CEF 12 10 292/442 53/65
CEF 12 16 292/442 53/65
CEF 12 20 292/442 53
CEF 12 25 292/442 65
CEF 12 31.5 292/442 65
CEF 12 40 292/442 65
CEF 12 50 292/442 65
CEF 12 63 292/442 65
CEF 12 80 292/442 65/87
CEF 12 100 292/442 65/87
CEF 12 125 442 65/87
NALF 17,5
CEF 17.5 6 292/442 65
CEF 17.5 10 292/442 65
CEF 17.5 16 292/442 65
CEF 17.5 20 292/442 65
CEF 17.5 25 292/442 65
CEF 17.5 31.5 292/442 65
CEF 17.5 40 292/442 65/87
CEF 17.5 50 292/442 65/87
CEF 17.5 63 292/442 65/87
CEF 17.5 80 442 87
CEF 17.5 100 442 87
CEF 17.5 125 442 87
NALF 24
CEF 24 6 442 53/65
CEF 24 10 442 53/65
CEF 24 16 442 53/65
CEF 24 20 442 65
CEF 24 25 442 65
CEF 24 31.5 442 65
CEF 24 40 442 65
CEF 24 50 442 65/87
CEF 24 63 442 65/87
CEF 24 80 442/537 87
NALF 36
CEF 27 6 442 65
CEF 27 10 442 65
CEF 27 16 442 65
CEF 27 25 442 87
CEF 27 40 442 87
CEF 36 6 537 65
CEF 36 10 537 65
CEF 36 16 537 65
CEF 36 25 537 87
CEF 36 40 537 87
NAL/NALF – Mounting and operation manual 31
